Features:
Pneumatically driven and electrically controlled system
Built-in ventilator, 10.4” LCD display screen
Closed; Semi-Closed; Semi-Open working mode
Applied for Adult and Pediatric
Main Technical Specifications:
Gas requirement: Medical oxygen and nitrous oxide with a pressure ranging from O2 & NO2: 0.32~0.6 MPa.
5-tubes Flowmeters, O2 & N2O & Air ; 0.1L/Min ~ 10L / Min;
Oxygen Flush: 25~75 L / Min
Respiration Mode: A/C,IPPV,SIPPV,IMV,SIMV,PCV,VCV,PEEP,SIGH,MANUAL
Tidal Volume: Adjustable range: 20 ~ 1500 ml, Display range:0~2000ml
I/E Ratio: 8:1 ~ 1:10
Two vaporizers: Enflurane/ Isoflurane/Sevoflurane (Optional:Halothane)
Vaporizer Setting Range: 0.5%~5%
Respiration Frequency : 1~100 bpm;
Lung compliance: ≤30 mL / kPa
IMV frequency: 1~20 bpm;
PEEP: 0 ~ 2.0 kPa
Ptr: -1.0kPa ~ 2.0 kPa
CO2 absorber capacity : 1 kg
Inspiratory Plateau: 0~1 S ;
O2 Concentration: 21%~100%
Optional: Patient monitor /Halothane
