CL-921
Careland
Features:
1.Fully stainless high-alloy steel structure
2.Digital display of working status, touch of key
3.Auto discharge the cool air, and steam discharging automatically after sterilization
4.Automatically shut off with beep reminding after sterilization
5.With two stainless steel sterilizing baskets
6.Easy to operate, safe and reliable
7.The drying system is optional, which can be equipped according to the customer’s request
Specification:
Model technical data | CL-921 | |||
Chamber volume | 35L(φ318×450)mm | 50L(φ340×550)mm | 75L(φ400×600)mm | 100L(φ440×650)mm |
working pressure | 0.22MPa | |||
Working temperature | 134℃ | |||
Max working pressure | 0.23 Mpa | |||
Heat average | ≤±1℃ | |||
Timer | 0～99min or 0～99hour59min | |||
Adjustment of temperature | 105～134℃ | |||
Power | 2.5Kw/AC220V.50Hz | 3Kw /AC220V.50Hz | 4.5KW AC220V.50Hz | |
Overall dimension | 480×460×850(mm) | 520×520×980(mm) | 560×560×980(mm) | 590×590×1080(mm) |
Transport dimension | 570×550×970(mm) | 590×590×1110(mm) | 650×630×1150(mm) | 680×650×1220(mm) |
G.W/N.W | 56Kg/ 42Kg | 68Kg/50Kg | 90Kg/70Kg | 105Kg/85Kg |
MODEL Technical Data | CL-921 | |
Chamber volume | 120L(φ480×660)mm | 150L(φ510×740)mm |
Working pressure | 0.22MPa | |
Working temperature | 134℃ | |
Max. working pressure | 0.23 Mpa | |
Heat average | ≤±1℃ | |
Timer scope | 0～99min | |
Adjustment of temperature | 105～134℃ | |
Power | 6KW/AC220V.50Hz | 6KW /AC220V.50Hz |
Overall dimension | 600×640×1140(mm) | 670×690×1130(mm) |
Transport dimension | 730×730×1270(mm) | 760×760×1270(mm) |
G.W/N.W | 125Kg/ 100Kg | 135Kg/110Kg |
Features:
1.Fully stainless high-alloy steel structure
2.Digital display of working status, touch of key
3.Auto discharge the cool air, and steam discharging automatically after sterilization
4.Automatically shut off with beep reminding after sterilization
5.With two stainless steel sterilizing baskets
6.Easy to operate, safe and reliable
7.The drying system is optional, which can be equipped according to the customer’s request
Specification:
Model technical data | CL-921 | |||
Chamber volume | 35L(φ318×450)mm | 50L(φ340×550)mm | 75L(φ400×600)mm | 100L(φ440×650)mm |
working pressure | 0.22MPa | |||
Working temperature | 134℃ | |||
Max working pressure | 0.23 Mpa | |||
Heat average | ≤±1℃ | |||
Timer | 0～99min or 0～99hour59min | |||
Adjustment of temperature | 105～134℃ | |||
Power | 2.5Kw/AC220V.50Hz | 3Kw /AC220V.50Hz | 4.5KW AC220V.50Hz | |
Overall dimension | 480×460×850(mm) | 520×520×980(mm) | 560×560×980(mm) | 590×590×1080(mm) |
Transport dimension | 570×550×970(mm) | 590×590×1110(mm) | 650×630×1150(mm) | 680×650×1220(mm) |
G.W/N.W | 56Kg/ 42Kg | 68Kg/50Kg | 90Kg/70Kg | 105Kg/85Kg |
MODEL Technical Data | CL-921 | |
Chamber volume | 120L(φ480×660)mm | 150L(φ510×740)mm |
Working pressure | 0.22MPa | |
Working temperature | 134℃ | |
Max. working pressure | 0.23 Mpa | |
Heat average | ≤±1℃ | |
Timer scope | 0～99min | |
Adjustment of temperature | 105～134℃ | |
Power | 6KW/AC220V.50Hz | 6KW /AC220V.50Hz |
Overall dimension | 600×640×1140(mm) | 670×690×1130(mm) |
Transport dimension | 730×730×1270(mm) | 760×760×1270(mm) |
G.W/N.W | 125Kg/ 100Kg | 135Kg/110Kg |
